Selenium Tutorials

Github Integration with Selenium

Complete Tutorial

What is Github?

Github is a web-based version-control that uses Git. It is a collaboration platform for software developers to integrate the code. It is open-source version control software so multiple users make separate changes to the project at the same time. It keeps both remote and local copies of your project and you can publish that project with your team members to use it and update it from there.

Advantages of Git Hub for Selenium.

  • Using Github in a central repository we can store our code from where all team members can use, share, modify the code with each other.
  • You can take a backup  of your project in case if your code remove from the local system
  • We can perform actions like code pull, commit, push, etc.
  • Github can easily track every change made by team members
  • By using Eclipse we can integrate Github with selenium so that we can push, pull, or commit changes from Git.
  • You can easily access all the committed code at any time from anywhere in the world
  • When multiple people are working on the same project they can update the project details and information to other team members simultaneously.

Prerequisite required for Selenium and Github Integration

The below components are to be installed before we start Selenium and Github integration.

  • Tomcat Installation
  • Jenkins Installation
  • Maven Installation

How to Install Git?

We follow the below steps to install Git

Step 1: Open the Browser and navigate to the URL- https://git-scm.com/

Step 2: Click on the Download button for the latest stable release as shown in the below image.

Step 3: Click on Downloads for windows to begin the installation

Github Integration with Selenium

Step 4: To start the installation process double-click on the downloaded setup file.

Step 5: Click on the Next button

Github Integration with Selenium

Step 6: Select the location where you want to install Git. Click on the Next button.

Github Integration with Selenium

Step 7: Select the following components which you want to install as shown in the below image. Click on the Next button.

Github Integration with Selenium

Step 8: On this wizard, you find an option to create a shortcut. By default, the Start Menu folder is pre-selected. Give the location if you want to change, else leave it the setting default. Click on the Next button.

Github Integration with Selenium

Step 9: In this step,

  1. Select the second option “Use Git from the Windows Command Prompt” by selecting this we will be able to run Git from the command line and
  2. Click on the next.
Github Integration with Selenium

Step 10:

  1. Select the checkbox “Use OpenSSH”, which help us to execute the command from the command prompt.
  2. Click on the Next button.
Github Integration with Selenium

Step 11: In this step,

  1. Select the checkbox “Checkout windows-style, commit Unix-style line ending” and Click on the Next button.
Github Integration with Selenium

Step 12: In this step,

  1. Check the option “Use MinTTY is the default terminal of MSys2” for Git Bash
  2. Click on the Next button
Github Integration with Selenium

Step 13: In this step,

  1. Check the option “Default(fast-forward or merge)
  2. Click on the Next button
Github Integration with Selenium

Step 14: Choose the option Git Credential Manager and click on the Next button

Github Integration with Selenium

Step 15: In this step,

  1. Check the option “Enable file system caching
  2. Click on the Next button
Github Integration with Selenium

Step 16: Click on the Install button

Github Integration with Selenium
Github Integration with Selenium

Note: Once the installation is completed, we need to verify whether git was executed successfully or not. To verify that, open the Command Prompt and type “Git” and hit the “Enter” key. If the below screen displayed means then it means that it is installed successfully.

Github Integration with Selenium

Set Up Eclipse with Git Plugin

Step 1: Launch the Eclipse and click Help ->Click on install new software

Github Integration with Selenium

Step 2: The below screen will be displayed and click on Add button.

Github Integration with Selenium

Step 3:

  1. Type the name “EGIT” and
  2. Enter the location https://download.eclipse.org/egit/updates/ then
  3. Click on the Add button.
Github Integration with Selenium

Step 4: Click on the Select All and Click Next button

Github Integration with Selenium

Step 5: Click on the Next and select the option ‘I accept the terms of the license agreement’ then click on the Finish button.

Github Integration with Selenium

Restart the Eclipse.

Creating a Repository on GitHub

To create a repository on GitHub follow the below steps:

1. Navigate to the Url https://github.com/.
2. Sign-Up for git hub.
3. Sign-Up with valid credentials.
4. Click on the “Create Repository” as shown in the below image.

Github Integration with Selenium

5. Enter the name of the repository in the “Repository name” text box.
6. Click on the “Create Repository” button.

Github Integration with Selenium

Selenium Integration with GitHub using Eclipse IDE

Below steps are involved in the Github Integration with Selenium Using Eclipse IDE

Step 1: Launch the eclipse and then navigate to the project

Step 2: Right-click on the project and select “Team” then

Step 3: Click on the Share Project

Github Integration with Selenium

Step 4: Select the Repository. If data is not displayed in the drop-down, then click on the Create.

Github Integration with Selenium

Once we click on the Finish button, we can notice the following change in the project structure of your Selenium project.

Github Integration with Selenium

Step 5: Right-click on the project and Navigate to Team ->Commit.

Github Integration with Selenium

Step 6: Right-click on the Selenium project and navigate to Team and click on Add to Index.

Step 7: Enter the commit message and click on the Commit button.

Github Integration with Selenium

This will add all your Test Cases files to staged changes.

Step 8: In the Eclipse Open Git repository tab.

Note: Follow the below steps if the Git repository tab does not open by default

a) Navigate to Windows Tab in Eclipse -> Click on Show view -> Click Other.
b) Expand the Git folder and select, Git repositories, and Git Staging, and click on the Open button.

Github Integration with Selenium

Step 9:  Right-click on the remote and navigate to Create Remote under the Git Repository tab.

Github Integration with Selenium

Step 10: You can see a new pop-up window got open, and enter the remote name. Leave the other settings as same and click on the Create button.

Step 11: Another pop-up window will got open and click on the Change button

Github Integration with Selenium

Step 12: Provide the URL and your login credentials of the GitHub account as shown in the below image, and click on the Finish button.

Github Integration with Selenium

Step 13: Once the configuration process is finished, select the branch to commit changes. Click on the Advanced button as shown in the below image.

Github Integration with Selenium

Step 14: Select your branch and click on the Add Spec button.

Github Integration with Selenium

Step 15: Click on the Finish button and you will find a folder with the name you provided under Remote.

Github Integration with Selenium

Step 16: Right-click on the URL of the red arrow, and click on Push.

Github Integration with Selenium

Step 17: Thus, all the changes were made and your Test Cases will get committed to the repository.

Github Integration with Selenium

Adding a Maven Project to GitHub Repository

Step 1: Open eclipse and click on File -> New -> Project -> Maven Project

Github Integration with Selenium

Step 2: Check the option “Create a simple project” and click on the “Next” button.

Github Integration with Selenium

Step 3: Enter Group Id and Artifact Id as “MyProject” and click on the “Finish” button.

Github Integration with Selenium

Step 4: Create a new package “mySeleniumPackage” under src/test/java of our Maven project and click on the “Finish” button.

Github Integration with Selenium

Step 5: Under mySeleniumPackage create a new class “OpenFacebook” and enable main() method.

Github Integration with Selenium

Step 6: Update the pom.xml file with Selenium and TestNG dependencies

<project xmlns=“http://maven.apache.org/POM/4.0.0” xmlns:xsi=“http://www.w3.org/2001/XMLSchema-instance” xsi:schemaLocation=“http://maven.apache.org/POM/4.0.0 https://maven.apache.org/xsd/maven-4.0.0.xsd”>

  <modelVersion>4.0.0</modelVersion>
  <groupId>MyProject</groupId>
  <artifactId>MyProject</artifactId>
  <version>0.0.1-SNAPSHOT</version>
  <dependencies>
<dependency>
<groupId>org.seleniumhq.selenium</groupId>
<artifactId>selenium-java</artifactId>
<version>3.141.59</version>
</dependency>
<dependency>
<groupId>org.testng</groupId>
<artifactId>testng</artifactId>
<version>7.1.0</version>
</dependency>
</dependencies>
</project>

Step 7: Create a Selenium test to open Facebook home page and get the title of the webpage

package mySeleniumPackage;
import org.openqa.selenium.WebDriver;
import org.openqa.selenium.firefox.FirefoxDriver;
import org.testng.annotations.Test;
public class OpenFacebook {
@Test
public void testcase() {
WebDriver driver;
System.setProperty("webdriver.gecko.driver", "C:\\drivers\\geckodriver.exe");
driver = new FirefoxDriver();
driver.get("https://www.facebook.com");
System.out.println(driver.getTitle());
driver.close();
}
}

Step 8: Create an xml file named “test.xml” to run the created testcase. Enter your package name(mySeleniumPackage) and the class name(OpenFacebook)

<!DOCTYPE suite SYSTEM "http://testng.org/testng-1.0.dtd">
<suite name = "Suite">
<test name="Test">
<classes>
<class name="mySeleniumPackage.OpenFacebook"/>
</classes>
</test>
</suite>

Step 9: Right-click on testng.xml file > Select Run As and Click on TestNG Suite

Creation of public GIT Repository?

Step 1: Login to www.github.com and click the ‘New” button to create a new repository

Github Integration with Selenium

Step 2: Enter the name of your repository “SeleniumProject1”, select Public, and Click on the “Create repository”

Github Integration with Selenium

Step 3: This will create a public repository in github.com and it can be accessed using the URL – https://github.com/xxxx/SeleniumProject1

Pushing your Selenium Project to GitHub

Step 1: Go to the Eclipse, select your project “MyProject” -> Right Click -> Team -> Share Project

Step 2: Configure Git repository to create a local repository of our Selenium project in our system. Select the check box “Use or create the repository in parent folder” and click “Create Repository” and click on the “Finish” button. This will create a .git file in the physical location of the project. In our case, the local repository is located at “C:\Users\hp\eclipse-workspace\MyProject.git”

Github Integration with Selenium

Step 3: Right-click on the project -> Team -> Commit, to push the project to a remote repository.

Github Integration with Selenium

Step 4: Eclipse will open a “Git Staging” window with 3 sections – Unstaged Changes, Staged Changes, and Commit Message.

Step 5: Unstaged Changes are the new files that need to get updated in the shared repository. We need to move Unstaged Changes to Staged Changes to add code to the shared repository. Once moved, give a “Commit message” and click on “Commit and Push”.

Github Integration with Selenium

Step 6: Enter the shared repository details where we want to push the Selenium code. Also, give the Authentication credentials details to connect to the shared repository and push the code

Github Integration with Selenium

Step 7: Click on the Push button

Step 8: Enter the credentials details once again to push

Github Integration with Selenium

Step 9: We will get a confirmation message like below, once the project got pushed successfully to the remote repository.

Github Integration with Selenium

Step 10: Go to the remote repository and refresh the page.

Github Integration with Selenium

This is how we will create a Selenium project in eclipse and update it in the GIT repository.

Conclusion:

  • Github is a web-based version-control that uses Git.
  • It is a collaboration platform for software developers to integrate the code.
  • It is an open-source version control software so multiple users make separate changes to the project at the same time.
Github Integration with Selenium
